Description

マイクから入力したオーディオ信号の「オーディオ波形」と「振幅スペクトル」(FFT演算結果の周波数ごとの大きさ)の同時表示に対応したRTAアプリです。
(FFT:高速フーリエ変換、RTA:Real Time Analyzer)
◆ 本アプリの特長
・オーディオ波形/振幅スペクトルの同時表示に対応
・縦向き/横向きの両対応
・オーディオ波形/振幅スペクトルの表示構成の選択が可能
・FFTサイズの選択が可能
・窓関数の選択が可能(振幅スペクトル演算で使用)
・振幅スペクトルのX方向(周波数)の表示方法の選択が可能(線形/対数)
・振幅スペクトルのピーク値とその周波数を表示
・ピークホールド(振幅スペクトルの過去のピーク値を保持した結果を表示)
・オクターブ分析(振幅スペクトルをオクターブバンドに分類して表示)
・オーディオ信号の生成(4種類の波形)
・ノイズ信号の生成(ホワイトノイズ、ピンクノイズ)

◆ 設定項目
[1. 画面構成]
画面構成の選択が可能
・Wave : オーディオ波形のみを表示
・Spectrum : 振幅スペクトルのみを表示
・Vertical : オーディオ波形/振幅スペクトルを縦に並べて表示
・Horizon : オーディオ波形/振幅スペクトルを横に並べて表示
[2. スペクトル バーの配色]
振幅スペクトルのバーの配色を選択することができます。(単色、カラフル)
[3. FFTサイズ]
FFTを行うときに使用するサンプル数の選択が可能(1024, 2048, 4096, 8192)
FFTサイズの値が小さいほど表示の更新は速いですが、振幅スペクトルが取得できる周波数の数は少なくなります。
FFTサイズの値が大きいほど表示の更新は遅いですが、振幅スペクトルが取得できる周波数の数は多くなります。
[4. 窓関数]
振幅スペクトルの計算で使用する窓関数(FFTを行う直前に乗算)の選択が可能
・Hann : ハニング窓
・Hamm : ハミング窓
・Blkman : ブラックマン窓
・None : 窓関数なし
[5. スペクトル X方向 表示タイプ]
振幅スペクトルのX方向(周波数)の表現方法を選択できます。
・Linear(線形) : 等間隔に分布
・Log(対数) : 対数的に間隔が広がる
[6. スペクトル ズーム可能な向き]
振幅スペクトルのズーム可能な向きを、X方向(周波数)/Y方向(振幅)から選択します。
(使いやすさを考慮して、選択した一方の向きのみをズーム可能な動作仕様といたしました。)
[7. ピークホールド]
振幅スペクトルの過去の最大値(ピーク値)を保持した結果を表示します。
[8. オクターブ分析]
振幅スペクトルをオクターブバンドに分類した結果を表示します。
分割方法:
・FFT : スペクトル表示(従来方式)
・1/12, 1/6, 1/3, 1 オクターブ : オクターブバンドに分割した表示(数値が大きいほど、バンド幅も大きい)
計算方法:
・Max(最大値) : 各バンド内の最大スペクトル値を表示
・Average(平均値) : 各バンド内の平均スペクトル値を表示
[9. オーディオ信号の生成]
選択している波形のオーディオ信号の生成が可能
・4種類の波形が選択できます。(サイン波、三角波、矩形波、ノコギリ波)
・20Hz - 20000Hz の範囲で周波数の値を設定することができます。
[10. ノイズ信号の生成]
選択しているノイズ信号の生成が可能
・2種類のノイズが選択できます。(ホワイトノイズ、ピンクノイズ)
・音量の調整が可能です。

◆ その他
・オーディオ波形/振幅スペクトルの画面をY方向にピンチ・イン/アウトすることで、中央を中心に縮小/拡大できます。(倍率:0.5〜2.0)
・振幅スペクトルの画面をX方向にピンチアウトすることで、拡大できます。(倍率:1.0〜16.0)
・オーディオ波形表示の縦線の間隔は 2 mSecです。
・振幅スペクトルの計算は、vDSPライブラリを使用しています。
・Bluetoothの接続方針を選択することが可能です。(使用しない、HFP、A2DP)

複数のオーディオ信号が必要な場合は、本アプリの設定画面のリンクから「マルチ信号発生器 - Wave Oscillator」をお試しください。
6チャンネル(最大16チャンネル)のオーディオ信号(サイン波、三角波、矩形波、ノコギリ波)を同時に生成することが可能なアプリです。
アプリ内課金で広告の非表示が可能です。もし本アプリを気に入っていただければ、ご利用いただけると幸いです。
